PMD55B-6594/0 PMD55B-BFBACBH37FCASAJA1D+Q1VD Deltabar PMD55B - Differential Pressure Transmitter

Approval:BFATEX/IEC II 2G Ex db IIC T6 Gb
Output:BA2-wire 4-20mA HART
Display; Operation:CSegment display w/o buttons
Housing; Material:BSingle compartment; Alu, coated
Electrical Connection:HThread NPT1/2, IP66/68 NEMA Type 4X/6P
Pressure Type:3Differential
Sensor Range:7F500mbar/50kPa/7.5psi
Calibration; Unit:CNominal value; kPa/MPa
Installation:AHorizontal impulse line, left side high pressure, with side vent
Process Connection:SAJNPT1/4-18 IEC61518 UNF7/16-20, 316L
Membrane Material:A316L
Fill Fluid:1Silicone oil
Seal:DFKM
>>Accessory Enclosed:Q1Mounting bracket, wall/pipe, 316L
>Regional Device Adaption:VDChina

Specs at a glance
Accuracy
Standard:
up to 0.075 %
Platinum:
up to 0.055 %
Process temperature
-40°C...+110°C (-40°F...+230°F)
Pressure measuring range
30 mbar.... 40 bar (0.45 psi... 600 psi)
Main wetted parts
316L, AlloyC
Material process membrane
316L, AlloyC
Measuring cell
30 mbar...40 bar
(0.45 psi...600 psi)

Field of application
This transmitter belongs to the new Deltabar generation. It is robust and easy to operate either locally or remotely. The transmitter can be controlled wireless via app on a mobile device using a secure Bluetooth connection. The PMD55B allows condition-based maintenance which increases efficiency in technical service significantly.
The software is designed to simplify the handling. Intuitive wizards guide you through the setup and proof testing of the device which minimizes operating errors.

• Pressure measuring range: up to 40 bar (600 psi)
• Static pressure up to 250bar (3750psi)
• Accuracy: up to +/-0.055%

Benefits

• Wireless control of the device in the process area with the SmartBlue App without interrupting the process
• Reduce on site accidents and protect equipment when instruments are in difficult to reach areas
• Reduce systematic failures - error free SIL commissioning and instrument guided proof testing

Common related models:

Important Terms:

1. Place of delivery (EXW/FOB/CIF): EXW

2. Packing cost: For free

3. Unit weight: Kg/lbs 8kg

4. Unit dimensions: (W x L x H) : 40*35*30cm

5. HS Code: 90261000

6. Payment terms: TT

7. Warranty: 12 months

Our Advantage:

Best possible prices and delivery time

Long time experience in the field

Well trained staff

Own warehouse facilities

Best relationships with branch office of manufacture

Flexible and individual service for you

Cheap and safe forwarder for shipments (air)

Frequently Asked Questions:

Q: Does your goods are new and original?

A: Yes, they are new and original.

Q: How long warranty?

A: One-year warranty.

Q: Does any certificates can be provided?

A: Yes, it depends on what product you request, please check details with our sales.

Q: Varied payment methods.

A: We adopt T/T, alipay and paypal and Currency in EURO,USD,RMB

Q: SHIPPING:

A: We can shipping all over the world.via DHL,UPS,Fedex,TNT and IPS,PDE,BRE,KARAPOST etc.

Our Product Range:

Transmitter, Safety barries, Flow meters, Probe, Sensor, Transducer. Valves,Analysis meter, Positioner, Acuator, etc.

Great System In.(GSI) a name synonymous with Process Control Instrumentation and Electrical and Instrument and Solution Provider have established themselves as a Quality Leader since its inception in 1998 based at Hong Kong ( China ).

For more than 26 years, we have successfully executed many prestigious orders by supplying Sophisticated Electronic Instruments and Control Systems and HT Panel and LT and Panel. Indigenization of the instruments of our product range have been in hand with our commitment to the manufacture of safe, reliable and quality instrument. Our thrust today is in the field of microprocessor based instrumentation and control systems. A knowledge inspiring and skilled arena that we are in, we are staffed to meet the dictates of the field and thus can provide various control and monitoring software packages for Instrumentation and control.

Application Gallery

Power : Feed Water (Drum Level & DP across Drum Level), Furnace Vacuum, SH Steam Temp Stage I & II (L&R), Dearator Level, Condenser Hotwell Level and REC, HP Heater Level, LP Heater Level, Gland Seal Steam Pressure, Gland Steam Temperature, Thermal Load, FD, PA and Vapor Fan Control

Oil & Gas : Platform & Pipeline, Catalytic Cracking, Distillation Columns, Blending, Reactors

Pulp & Paper : Stock Preparation, Chest Box, Bleaching

Mining : Ore Dressing, Pyro/Hydro Processing, Electrolytic Refining, Crushers, Ball Mills, Classifiers, Filters, Flotation Devices, Magnetic Separators, Calcining Kilns, Digesters, Evaporators

Food & Beverages : Evaporators, Blending & Batching, Fermenting

Steel : Blast Furnaces, Continuous Casting, Reheating Furnaces, Biological Waste Treatment, Annealing Lines Sintherization

Water & Waste Water : Filter Backwash, Chemical Feed, Clear well Level, Finished Water Pumping, Remote Workstation Monitoring, Sludge Process, Sequencing Batch Reactor Plants, Rotating Biological Contactor Plant, Sludge Dewatering, Incinerator Control, Return and Waste activated sludge pumping
